DyneticPro Motor
1 / 4
| Parameter | Specification Details |
|---|---|
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Gearmotor Model | Ratio | Rated Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed | Current | Speed | Current | Torque | Current | Torque | |||
| RPM | mA | RPM | mA | N.m / Kgf.cm | mA | N.m / Kgf.cm | |||
| GM2240 | 1 : 241 | 4.5 VDC | 52 | ≤ 50 | 40 | ≤ 120 | 18 / 180 | ≤ 350 | 0.18 / 0.18 |
| 58 | ≤ 65 | 50 | ≤ 130 | 24 / 240 | ≤ 680 | 0.2 / 2.0 | |||
| 68 | 75 | 56 | ≤ 140 | 26 / 260 | ≤ 750 | 0.22 / 2.2 | |||
| PMDC MOTOR Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||
|---|---|---|---|---|---|---|---|---|---|
| Speed | Current | Speed | Current | Torque | Current | Torque | |||
| RPM | mA | RPM | mA | mN.m / gf.cm | mA | mN.m / gf.cm | |||
| SL-N20 | 04510500 | 4.5 VDC | 10500 | ≤ 30 | 8250 | ≤ 80 | 0.2 / 2.0 | ≤ 300 | 1.05 / 10.5 |
| 04514000 | 4.5VDC | 14000 | ≤ 40 | 12000 | ≤ 130 | 0.25 / 2.5 | ≤ 680 | 1.5 / 15 | |
| 04516500 | 4.5VDC | 16500 | ≤ 50 | 13500 | ≤ 160 | 0.25 / 2.5 | ≤ 750 | 1.8 / 18 | |
We are a factory specialized in producing motors for more than 14 years. Our professional R&D team and mature management system ensure a highly reliable and satisfying manufacturing experience.
To confirm premium quality, each production stage—from incoming raw materials to final shipment—is carefully checked at every single step. High quality is the core foundation of our development.
A: We are a dedicated factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
A: We can set up an online transaction order for new customers, allowing payments via credit card (MasterCard, Visa, etc.). We also accept payments through PayPal, TT, and other popular payment methods.
A: Yes, we can fully customize motor specifications (including voltage, speed, torque, and dimension interface) according to our customers' specific requirements.
A: Yes, our motors hold key certifications such as CE, FCC, ISO, and others. If you have specific regional certificate requirements, we can also assist in applying for them.
A: We assign professional quality checkers to every stage of the production line. Once fully assembled, each motor undergoes rigorous testing using advanced equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testing Rigs, Temperature Test Machines, and Noise Testing systems.
A: Production lead time typically ranges from 15 to 30 days depending on the ordered quantity, customized engineering needs, and current factory scheduling.
