DyneticPro Motor
1 / 3
------ RS - 755 H
------ RS - 775 H
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-770H 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 | |
| RS-775H 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 | |
We are a factory specialize in producing motors more than 14 years, and we have three factories. Our professional R&D team, mature management, and experienced engineers and sales team will bring you a pleasant shopping experience.
In order to confirm quality, from the moment we receive material to shipment, every step of the way is carefully checked. Quality is the basis of our development.
Q1: Are you a trading company or manufacturer?
A: We are a factory. We specialize in micro DC motors and DC gear motors for more than 14 years.
Q2: What is the payment term for a new customer?
A: We can draw up an Ali Assurance Order Online for our new customers, which can be paid online with Master Card, Visa, etc. Customers can also pay with PayPal or TT, etc.
Q3: I cannot find a suitable motor on your website, can you customize the motor for me?
A: Yes, we can customize a suitable motor according to our customers' specific requirements.
Q4: Do you have certificates for the motors?
A: Yes, we have CE, FCC, ISO, etc. If you have other certificate requirements, we can apply for them for you.
Q5: How is your Quality Control?
A: We have professional checking staff on every production line process. After finishing the whole motor, we use specialised quality testing machinery such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, Noise Testers, and more.
Q6: Can the length of the shaft be customized?
A: Yes, the length of the motor shaft can be fully customized based on your specific application requirements.
