390 Dc Motor for Machine Fan From Shenzhen Supplier 12v 6000rpm Motor

Send Inquiry

Product Description

390 DC Motor for Machine Fan 12v 6000rpm Motor

Product Details

⚙️ Motor Customized Specification is available. Please inquire for custom designs.

Reference Drawing

------ RS - 365

------ RS - 385

------ RS - 395

📏 The length of the shaft can be customized according to your application requirements.

Reference Datasheet

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-390SH	20156R	6.0~12.0	12VDC	5000	0.08	4243	0.33	6.07/61.9	2.72	2.22	42.2/430
RS-390SH	2975	6.0~12.0	12VDC	12000	0.29	10165	0.33	5.75/58.6	1.31	8.9	80.4/820
RS-395SH	15130	6.0~12.0	12VDC	3650	0.66	2949	0.25	5.83/59.5	1.8	1.06	30.4/310
RS-395SH	15100R	6.0~24.0	24VDC	10300	0.07	8893	0.38	7.09/72.3	6.68	2.66	54.9/560

Frequently Asked Questions (FAQ)

Q1: What are the primary applications of the 390 DC Motor?

The 390 DC Motor is highly versatile and commonly utilized in machine fans, cooling devices, small home appliances, and various smart hardware systems requiring stable high-speed performance.

Q2: Can the shaft length of the RS-390 and RS-395 motors be customized?

Yes, the length of the shaft can be customized according to your specific structural and application demands. Custom motor specifications are available upon request.

Q3: What is the operating voltage range for these PMDC motors?

Depending on the model, the operating voltage range varies. For instance, the RS-390SH operates within 6.0V to 12.0V, while the RS-395SH (model 15100R) can operate up to 24.0V.

Q4: How does the no-load speed differ between the RS-390SH motor models?

Under a nominal 12VDC, the RS-390SH 20156R features a no-load speed of 5,000 RPM, whereas the RS-390SH 2975 model achieves a higher no-load speed of 12,000 RPM.

Q5: Are technical datasheets available for the RS-365, RS-385, and RS-395 variants?

Yes, the technical specifications, operating ranges, speeds, currents, torque, and power values are detailed in the datasheet section above for quick reference.
