DyneticPro Motor
1 / 5
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| PMDC MOTOR Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m / gf.cm) | Power (W) | Current (mA) | Torque (mN.m / gf.cm) | ||
| FK-280SA | 4525 | 1.0~2.0 | 1.2VDC | 8670 | 730 | 6560 | 2240 | 1.74/17.7 | 1.3 | 8430 | 9.61/98 |
| 16245 | 6.0~12.0 | 12VDC | 7300 | 60 | 6027 | 290 | 3.4/34.6 | 2.15 | 1350 | 19.5/198 | |
Why choose us:
1. Expert Motor Manufacturing
We are a dedicated factory specializing in producing high-quality motors for more than 14 years. With state-of-the-art production facilities, a professional R&D team, mature management processes, and highly experienced engineers, we ensure a reliable and pleasant partnership experience.
2. Strict Quality Control
Quality is the foundation of our sustainable development. To guarantee superior performance and reliability, every component is rigorously checked throughout the manufacturing process, from incoming materials to final shipment testing.
3. Premium Professional Services
Verified manufacturer holding high industry credibility.
100% on-time delivery rate ensuring your products arrive on schedule.
Standard samples ready within 2 weeks; custom samples within 3 weeks.
Prompt response system, ensuring messages are replied to within 2 hours.
