SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

1 / 4

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Tilt font to know more parameters!

Application

Frequently Asked Questions

Q1: What are the primary specifications of the RC-370SH-4730 PMDC motor?

A1: The RC-370SH-4730 motor operates at a nominal voltage of 4.5 VDC. It features a no-load speed of 17,500 RPM (with 550 mA current) and a rated speed of 15,199 RPM at 3.63A (3,630 mA), yielding an output power of 11.51W.

Q2: What is the operating voltage range for these PMDC motors?

A2: The voltage range varies by model. For instance, the RC-370SH-4730 operates between 3.0V and 5.0V (nominal 4.5V), while the RC-370SH-18139 runs between 6.0V and 12.0V (nominal 12V). The RF-370CA has a wider range from 6.0V to 24.0V.

Q3: What are the typical applications for the 370-series micro motors?

A3: These motors are commonly applied in miniature gearboxes, smart security systems, battery-powered devices, flat geared setups with magnetic encoders, children's electric toys, and low-RPM DC electric gear drive systems.

Q4: How does the stall torque differ between the RC-370SH models?

A4: The RC-370SH-4730 model delivers a stall torque of 55 mN.m (561 gf.cm) at 4.5 VDC, whereas the RC-370SH-18139 model provides 37.5 mN.m (382.5 gf.cm) when operating at 12 VDC.

Q5: Which model is best suited for low power consumption at higher nominal voltage?

A5: The RF-370CA model is ideal, operating at a nominal 24 VDC with a very low no-load current of only 3 mA and a rated current of 8 mA, delivering a power output of 0.1W.

Q6: Are the dimensions and parameters customizable?

A6: Yes, the technical data table indicates various windings and configurations (like 370CA, 370CH, and 370SH) to cover different voltage inputs, speeds, and torque values depending on your project requirements.
