DyneticPro Motor
1 / 4
Motor Customized Specification, Please contact us.
The length of shaft can be customized, Please contact us.
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-750H (7032R) | 6.0 ~ 12.0 | 12 VDC | 15000 | 1.79 | 12671 | 7.52 | 48.6 / 496 | 66.6 | 55.6 | 393.1 / 4010 | |
| RS-755H (7512R) | 3.0 ~ 6.0 | 6 VDC | 9500 | 2.26 | 8123 | 9.31 | 45.1 / 460 | 38.2 | 66.34 | 306.9 / 3130 | |
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team, mature management structure, and experienced engineers bring you a reliable and smooth purchasing experience.
To confirm peak quality, every stage of our operations—from incoming material inspection to final shipment—is carefully checked. Quality serves as the cornerstone of our corporate development.
We are a high-credibility, golden-level seller focused on long-term client partnerships.
100% on-time delivery rate to ensure your products arrive exactly when needed.
Standard samples produced within 2 weeks. Custom samples completed within 3 weeks.
Timely communication support: all inquiries and messages will receive replies within 2 hours.
A: We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
A: We can establish an online Assurance Order for our new customers. Payment can be processed online via Credit Cards (Visa, MasterCard), PayPal, or wire transfer (T/T).
A: Yes, we can custom-build a motor tailored to your target application and performance requirements, including customized voltage, speed, torque, and shaft length.
A: Yes, our motors are certified with CE, FCC, ISO, and other relevant compliance standards. If you have additional certification requirements, we can apply for them for you.
A: We employ professional QC staff at every stage of the production line. Once assembly is complete, we perform comprehensive performance evaluations using advanced testing equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Testers, and Noise Testers.
A: Standard motor samples are completed within 2 weeks, and fully customized motor samples are processed and finalized within 3 weeks.
Contact us today for custom solutions, bulk order details, or quotation requests.
